Flowmeter »FLUX 0«, 0 … 200 Nl/min, Ø 8 mm, 1 … 5 V
(List price: €213.32)
€213.32
List price:
€213.32 / piece
Your price:
€213.32 / piece
ERP-Info
Scale of prices
Quantity
Price
/
Sales info
Price unit:
1
Quantity unit:
piece
Content:
1 piece
excl. VAT and shipping
You can see the exact availability after logging in
In stock
SKU
148230
Customer product code
Type Number
9000978V2
Article name from customer
EAN-Code
4047322799652
Flowmeter »FLUX 0«, 0 … 200 Nl/min, Ø 8 mm, p1 = -0.9 … 8 bar, T = 0 … 50 °C, 12... More
You can see the exact availability after logging in
List price:
€213.32 / piece
Your price:
€213.32 / piece
ERP-Info
Scale of prices
Quantity
Price
/
Sales info
Price unit:
1
Quantity unit:
piece
Content:
1 piece
Productdata
Flowmeter »FLUX 0«, 0 … 200 Nl/min, Ø 8 mm, p1 = -0.9 … 8 bar, T = 0 … 50 °C, 12 … 24 V DC, 1 … 5 V, PNP, 2 m cable
Thermal flowmeters of the »FLUX 0« series are miniaturized devices used for monitoring changes in flow and consumption, as well as for measuring leaks and energy efficiency. They come complete with push-in fittings. For the best results, the input pipe must have a straight section of at least 80 mm in length or more, otherwise the measurement will be inaccurate. They have two digital outputs and one analogue output, each of which can be freely set to measure the instantaneous flow rate, the accumulated flow rate or the pressure, therefore they can perform the function of flowmeter, flow switch, pressure gauge or pressure switch.
Article No.
148230
Series
FLUX 0
Size
0
Max. input pressure
10 bar
Min. operating pressure
-0.9 bar
Max. operating pressure
8 bar
Min. temperature range
0 °C
Max. temperature range
50 °C
Connection
plug connector Ø8 mm
Flow measuring range min.
0 Nl/min
Flow measuring range max.
200 Nl/min
Analogue output
1 - 5 V
Digital output
2 PNP
Display
with
Pressure sensor
with
IO-Link
without
Function
flowmeter/switch, pressure gauge, pressure switch
Measured values output
via cable and display
WiFi
without
Compatible with app
no
Medium
filtered, unlubricated compressed air and neutral gases
Housing
technopolymer
Supply voltage range
12 to 24 +/-10 % V DC
Operating voltage min.
10.8 V DC
Operating voltage max.
26.4 V DC
Hysteresis
adjustable
Flow direction
unidirectional
Measuring system
thermal
Protection IP
IP40
Scope of delivery
connector with 2 m cable
A
83.0 mm
B
52.0 mm
Country of origin
TW
REACH SVHC1 substance name
Lead
CAS no. SVHC 1
7439-92-1
RoHS materials notice
Rohs compliant
REACH Info
contains SVHC substance
Class name
MAX
Customs tariff number
90261021
Page No.
WEB
Downloads
Variants
| Art. No. | Type No. | Attributes | Max. input pressure | Function | Size | Connection | Availability | Price | Options |
|---|---|---|---|---|---|---|---|---|---|
| 148227 | 9000958A2 | 10 | flowmeter/switch, pressure gauge, pressure switch | 0 | plug connector Ø8 mm | You can see the exact availability after logging in | €213.32 List price: €213.32 / piece Your price: €213.32 / piece ERP-Info Scale of prices Quantity Price / Sales info Price unit: Quantity unit: piece Content: piece excl. VAT and shipping You can see the exact availability after logging in | ||
| 148228 | 9000958V2 | 10 | flowmeter/switch, pressure gauge, pressure switch | 0 | plug connector Ø8 mm | You can see the exact availability after logging in | €213.32 List price: €213.32 / piece Your price: €213.32 / piece ERP-Info Scale of prices Quantity Price / Sales info Price unit: Quantity unit: piece Content: piece excl. VAT and shipping You can see the exact availability after logging in | ||
| 148229 | 9000978A2 | 10 | flowmeter/switch, pressure gauge, pressure switch | 0 | plug connector Ø8 mm | You can see the exact availability after logging in | €213.32 List price: €213.32 / piece Your price: €213.32 / piece ERP-Info Scale of prices Quantity Price / Sales info Price unit: Quantity unit: piece Content: piece excl. VAT and shipping You can see the exact availability after logging in |
